All the electrical appliances adopt domestic excellent products.
All the drive gears are skewed tooth. It adopts high frequency quenchine, and part of them are cementite treated.
After milling, grinding and sprinkle lubricating, the driving precision and using life are greatly improved.
The mainframe, blower, phase motor, etc, adopt transducer control, the speed adjusting is steady, and it can save electricity
With auto chain feeding function, it can produce bigger cartons.
Each set has emergency stop switches, which can ensure the safety of the operators
| Model | Max.Sheet (mm) | Printing Area (mm) | Work Speed (Place/min) | Main Power (kw) | Paperboard Thickness |
|---|---|---|---|---|---|
| 2600 | 1450*2400 | 1450*2200 | 0-60 | 4.0 | 2-11 |
| 2800 | 1450*2600 | 1450*2400 | 0-60 | 4.0 | 2-11 |
| 3000 | 1450*2800 | 1450*2600 | 0-60 | 4.0 | 2-11 |
| 3200 | 1450*2400 | 1450*2800 | 0-60 | 4.0 | 2-11 |
| 3800 | 1450*2400 | 1450*2400 | 0-60 | 4.0 | 2-11 |
| 3000 | 1450*2600 | 1450*2600 | 0-60 | 4.0 | 2-11 |
| 3200 | 1600*3000 | 1600*2800 | 0-60 | 4.0 | 2-11 |
