| No | Name | Specifications |
|---|---|---|
| 1 | Working width | 1400--2200mm |
| 2 | Design speed | 100m/min |
| 3 | Thickness wallboard | Casting HT200/ thickness 130mm |
| 4 | Corrugated roller diameter | Φ280/270mm/ 48CrMo alloy steel |
| 5 | Pressure roller diameter | Φ280/270mm / 45# steel |
| 6 | Preheating roller diameter | Φ320mm/ 45# steel |
| 7 | Glue roller diameter | Φ215mm/ 45# steel |
| 8 | Gimbal drive,separation structure,independent drive box,enclosed gear oil immersion type lubrication ,can prolong the life of the gearing. | |
| 9 | Corrugated roller adopt 48CrMo high quality alloy steel,quenched and tempered,hardened,polished surface,corrugated dia. 280/270mm,surface hardness HRC60 degrees; Adopt pneumatic cylinders control up and down of corrugated roller. | |
| 10 | Pressure roller diameter Ø280/270mm,modulation processing with 45# carbon steel , machining and grinding off the surface chrome plated cylinder control up and down | |
| 11 | Pneumatic control supply glue,glue roller diameter Ø215mm, engraved with the pit-style textured back surface polished, hard chrome plated,doctor roller surface grinding and hard chrome plating. | |
| 12 | Electronic components and accessories:Adopt Schneider, Delixi brand. Pneumatic components.rotary joints,metal hose:YADEKE,Tengzhou brand. |
|
