| No | Name | Specifications |
|---|---|---|
| 1 | Working width | 1400--2200mm |
| 2 | Design speed | 150m/min |
| 3 | Thickness wallboard | Casting HT200/ thickness 180mm |
| 4 | Corrugated roller diameter | Φ320mm/48CrMo alloy steel |
| 5 | Pressure roller diameter | Φ320mm /45 steel |
| 6 | Preheating roller diameter | Φ400mm/45 steel |
| 7 | Glue roller diameter | Φ240mm/45 steel |
| 8 | Corrugated roller adopt 48CrMo high quality alloy steel,quenched and tempered,hardened,polished surface,corrugated diameter Ø320m,surface hardness HRC60 degrees;Adopt pneumatic cylinders control up and down of corrugated roller. | |
| 9 | Gimble drive,with independent driver box.Enclosed gear oil immersion lubrication, extend the life of the gear. | |
| 10 | Pressure roller diameter is Ø320mm which adopts 45# carbon steel modulation process. The roller surface is grinded and chromed, controlled by air cylinder to up and down. | |
| 11 | Vacuum adsorption to guide paper with a strong high-pressure turbine.With wind control device machine suction silencer | |
| 12 | Adopt electric adjust glue width (coated paste run independently,when the host stopped,to prevent the paste dry can be choosed.) | |
| 13 | Function:Glue amount with electric adjustment and digital display, foggy sprayer device for paper pre-heater; PLC touch screen can be chosed! | |
