Single & double strengthened nail are available
Nailing from 30-120 mm , auto-calculated; servo motor controls the nailing by Delta, Japan.
HD 5.7” color touch screen by Eview, Taiwan
PLC system and electrical devices by Siemens, Germany; photo-electricity switch and limit switch by autonics, Korea, high quality assured; the motor and reducer are made in Taiwan.
The reamer of pinhead is made by tungsten steel of Germany. Maching is exactitude by special heat – treatment and numerical control system
Fully electrical controlled and it can change the size in less tha one minute and handle easily without the relevant experience .
Nailing speed : 400nails /min
Number of Nails: 1-99
Automatic counter in the latter part ; deliver paper boxes in lot is fixed up for strapping
| Maximum Board Size | 2800x1515mm |
| Minimum Board Size | 550x300mm |
| Paper Height | 900mm |
| Nailing Form | 30-120mm |
| Nailing Speed | 400 Nails/Min |
| Total Power | 5kw |
| Number of Nails | 1-99 |
| Dimensions | 3300x2500x2000 |
